Measurement range in terms of flow velocity:
0 – 0.3 m/s to 0 –10 m/s (0 –1.0 ft/s to 0 – 32.8 ft/s).
0 – 0.1 m/s to 0 – 0.3 m/s (0 – 0.3 ft/s to 0 – 1.0 ft/s)
range is available optionally.
Accuracy:
< 1/2" to 18" ( 15mm to 450mm )>
±0.2 % of Rate*
* This pulse output error result is established under standard
operating conditions at Toshiba's admitted flow calibration
facility.
* Individual meter measurement error may vary up to ±0.5% of
Rate at 1.64 ft/s (0.5m/s) or more and ±0.3% of rate ±0.039
inch/s (1mm/s) at 1.64 ft/s or less.
* Current output: plus ± 8μA (0.05% of span.)
* Refer to individual calibration data for each individual
meter's measurement error.
< 20" and 24" ( 500mm and 600mm )>
±0.3 % of Rate*
* This pulse output error result is established under standard
operating conditions at Toshiba's admitted flow calibration
facility.
* Individual meter measurement error may vary up to ±0.5% of
Rate at 3.28 ft/s (1.0m/s) or more and ±0.3% of rate ±0.079
inch/s (2mm/s) at 3.28 ft/s (1.0m/s) or less.
* Current output: plus ± 8μA (0.05% of span.)
* Refer to individual calibration data for each individual
meter's measurement error.
