Device type

TP 38 165

TP 38 650

Temperature range

-35 ̊C to 165 ̊C

Ambient temperature to 650  ̊C

Tolerance

+/-0.1  ̊C

+/-0.2  ̊C

Stability

0.01  ̊C to 0.05 ̊C

0.03 ̊C to 0.1 ̊C

Resolution

0.01

Display

Versions

Monochrome, graphic display

Displays

Block and set temperature, difference, variance, min. and max. temperatures

Languages switchable

German / English / French / Spanish

Units

̊C /  ̊F / K / Ω / mV / mA

Operating elements

Membrane keyboard

Additional displays

Test piece temperature including the physical values

Temperature of the external calibration reference sensor

Block

Block material

Aluminium

Brass

Block bore

28 mm

Immersion depth

150 mm

Adapter sleeves

Inside diameter 1.5 mm to 25.0 mm in 0.5 mm steps

Epuipment features

Temperature steps

Gradient control

Computer interface

Logger function

Precision measuring instrument

Step tests, calibration runs

Implementation of ramp functions

Serial RS 232 C incl. transmission protocol

8 data sets with 6 values each

RTD, TC, mA, switch, calibration reference sensors

General data

Power supply

100..240 VAC, +/- 10 %, 50/60 Hz

230 VAC, +/-10%, 50/60Hz

100..115 VAC,+/-10%, 50/60Hz

Power consumptuon

Approx. 400W

Approx. 1000W

Dimensions (D x W x H)

Approx. 348 x 153 x 347 mm

Weight

Approx. 12kg

Approx. 10kg

Options

Service case, software, certificate, external calibration reference sensors
