| Product family |
56x |
| Dimensions |
96x48 mm |
| Limits |
2 Relay switch |
| Display |
LED |
| Number of digits |
6 |
| Control points |
12 Control points |
| mV Sensors |
- |
| Resistance input |
- |
| Thermo resistance |
- |
| Thermocouple sensor |
- |
|
Strain-gauge input
|
1,0mV 1,5mV 2,0mV 3,0mV 3,3mV |
| Standard signal input |
- |
| Interfaces |
Analogueue output 0...10V
Analogueue output 0...20mA
Analogueue output 2...10V
Analogueue output 4...20mA
|
| Protection max. |
IP 65 |
| Temperature |
-20...+65°C |
| Power supply |
10...30 VDC
90...260 VAC
|
2 limits, totaliser function, programmable characteristic curve, Min/Max value detection, scalable. Easy programming with running help texts and quick-start guide.
